Eco Slab Interlocking Patio Tiles
Sustainable, Heavy‑Duty Versatile ground protection system
Eco Slab interlocking patio tiles are a durable, versatile ground‑protection system made from 100% recycled plastic. Each lightweight slab covers 1.5 square feet and locks securely into place, creating a stable surface suitable for both temporary and permanent use. With the ability to bear loads of up to 100 tons per square foot, Eco Slab is strong enough for driveways, parking areas, patios, walkways, and event flooring. Only the slotted (permeable) version is available, ensuring excellent drainage and long‑term performance in all weather conditions.
Fast Installation for Temporary or Permanent Projects
Eco Slab installs quickly and dismantles just as easily, making it ideal for exhibitions, fairs, and short‑term events. On firm, level ground, the tiles can be used immediately; on soft or soggy soil, a roll‑out geogrid is recommended beneath the slabs. For permanent applications such as driveways or amenity areas, Eco Slab performs best when installed over a compacted stone base with a geotextile separation layer and a 1‑inch bedding layer of sharp sand or grit. The interlocking hooks ensure a secure fit, and the hexagonal shape allows for easy trimming with standard woodworking tools when edge adjustments are needed.
Ordering, Coverage, and Freight Information
All orders require a minimum of 72 tiles (108 sq ft), with optional add‑on packs of six tiles for additional coverage. One full pallet includes 354 slabs and covers 531 square feet. Shipping costs shown at checkout are estimates; your actual freight cost will be calculated after purchase. We will contact you to adjust the difference by crediting or debiting your card. If you prefer an exact freight quote before ordering, you’re welcome to call us at (231) 399‑0700 Ext. 7. Eco Slab offers long‑lasting strength, dependable performance, and sustainable construction—all in a simple, interlocking system designed for real‑world use.
.
Specifications:
Outer width 18⅛”
Inner width 15¾”
Height 1⅝”
Weight per slab 3.75 lbs
Coverage per slab 1.5 ft²
Slabs per pallet 354
Coverage per pallet 531 ft²
Material 100% recycled plastic
Connection Interlocking hooks
Color Gray or Brown
![]()
Temporary applications
Eco Slab is quick to install, easy to dismantle and ideal for events like exhibitions, shows and fairs. Lay Eco Slab directly onto firm, stable and level ground or flooring and use immediately. If the ground is soggy grass or soft soil, install a roll out geogrid between the ground and Eco Slab. If the ground is very soft and boggy, Eco Slab is not recommended without further ground preparation.
Permanent applications
Eco Slab is strong, durable and perfect for permanent applications like drive ways and amenity areas.
Step 1
Install an edge or curb to prevent movement of bedding materials. Make sure that the ground is strong enough to bear the expected loads. If not, lay 4–6” of free-draining compacted and levelled stone.
Step 2
Cover the sub-base with a non-woven needle-punched geotextile layer (with 6” overlaps) to keep the sub-base and bedding layer separate. Install, compact and level a 1” bedding layer of sharp sand or grit.
Step 3
Start from the edge or curb and install Eco Slab onto the bedding layer. Make sure the interconnecting hooks fit securely beneath each slab. Due to the hexagonal shape, a
straight edge leaves a half slab gap – Eco Slab is easy to cut with a circular saw or standard woodworking tools (for tricky areas, avoid cutting to less than a third of a slab).Work outwards from this first line, clicking further slabs together until the area is covered. An expansion gap of 1–2 cm / ⅜–¾” should be left between the Eco Slabs and
the border/curb. For immediate use, bed the new paved area down with a nylon covered plate vibrator.
Machining Guidelines for Plastic Materials
Sawing and Cutting
High‑speed band saws and circular saws with slightly crossed, carbide‑tipped teeth provide the best finish when cutting plastics. Shavings should be removed quickly to prevent smearing. Lengths may also be shortened with a chainsaw, though this method reduces accuracy.
Routing
For optimal routing results, use a large span cross‑section to help keep machining temperatures low. A high feed rate and depth of cut are recommended, while cutting speed should remain low. Routers with indexable carbide inserts can extend tool life and improve consistency.
Drilling
Spiral drill bits with a helix angle between 20° and 30° and a peak angle between 110° and 120° are suitable for most plastic materials. When drilling deeper holes, occasional relaxation strokes help reduce frictional heat and prevent material damage.
Planing
Standard hand planes or machine planers can be used effectively on plastics. Surface quality depends on feed rate, cutting speed, clearance angle, cutting angle, and the sharpness of the blade.
Deburring
Angle grinders should not be used for cutting plastics due to their high rotational speed. However, they are effective for removing burrs and smoothing edges after machining.
Tips for Working With Recycled Plastic Profiles
Fastening and Drilling
When bolting recycled profiles together, always pre‑drill the piece being fastened. The hole should be larger than the bolt, and elongated slots are recommended to accommodate temperature‑related expansion.
Painting
Recycled profiles are only partially paintable. The best results come from permanently elastic plastic paints (all‑weather paints) applied to a roughened and primed surface. Long‑term paint adhesion cannot be guaranteed.
Nailing
These profiles can be nailed conventionally or with a nail gun. Because the surface is more compact than wood, penetration requires more force, so plan fastening accordingly.
Flexibility and Support Spacing
Compared to wood or metal, recycled plastic has lower stiffness and higher flexibility. This should be considered when determining support spacing for docks, fences, patios, and similar structures.
Hammering
If hammering is required, use a mallet or a corner protector to avoid damaging the material.
Expansion and Installation
Boards, beams, and square profiles must not be press‑fitted. Due to temperature fluctuations, profiles may vary in length by up to ±1.5%. Always include an expansion gap during installation.
Sunlight and Storage
Sunlight can influence profile alignment and may cause components like fence posts to tilt. To prevent distortion, avoid storing profiles loosely in direct sun.
Technical Documentation
Structural verification tests, installation recommendations, and mounting instructions are available for many products and applications. These resources can be found in the Downloads section at hahnplastics.ca.
hanit® products can be machined using standard wood‑ and metal‑processing tools, but their material properties require a few considerations. Machining generally leads to higher tool wear, so carbide‑tipped tools are recommended. Because recycled profiles have a closed surface, machining may reveal a honeycomb‑like core structure, which is normal for this material. Some products are reinforced with steel and are labeled accordingly; these should not be cut or sawn to length or width. Any chips produced during machining should be collected with an appropriate extraction system so they can be reused.
